Newtesol has a welding department where we make and study the best materials and welding procedures to be used in manufacture looking for the best quality results on the union.
Welding procedure qualification is usually required before job execution. It must comply with ASME or EN-ISO-15614, the rules required by our customers.
Newtesol holds more than 200 approved processes both in butt-welding as in clad metal
We practice the following tests to our procedures:
- Dye Penetrant Test (1rst & 2nd layer)
- UT 100 % of the Overlay
- Transversal Bending of Face & Side (ASME – QW462.5/d)
- Chemical Analysis (ASME II C)
- Hardness HV 10
- Macrographic & Micrographic Test (Base material, HAZ, fusion line, 1st and 2nd Layer of the Overlay).
Additional tests required by our customers:
- Tensile test removing the weldoverlay
- Corrosion test by ASTM A262-E
- Disbonding tet by ASTM G 146/01
Nuevas Tecnologías de Soldadura has carried out disbonding tests with big success (0% disbonding) over their weld overlays on CrMo base materials and stailess filler material types 347 and 308, since the petrochemical industry demands high quality requirements over reactors construction.
The following charts contain the most outstanding procedures that we use:
I. Carbon steel + stainless steel
| Base material | Procedure | Welding material |
|---|---|---|
| SA 106 Gr B (P1) | GTAW (Auto) | ER 309LMo + ER 316L |
| SA 106 Gr B (P1) | GTAW (Auto) | ER 309L + ER 308L |
| SA 106 Gr B (P1) | GTAW (Auto) | ER 309L + ER 309L |
| SA 106 Gr B (P1) | GTAW (Auto) | ER 385 (904L) |
| SA 106 Gr B (P1) | GTAW (Auto) | ER 309L + ER 317L |
| SA 106 Gr B (P1) | GTAW (Auto) | ER 2594 (Super Duplex) |
| SA 106 Gr B (P1) | GTAW (Auto) | ER 2209 (Duplex) |
II. Chromium molybdenum alloy steel + stainless steelg
| Base material | Procedure | Welding material |
|---|---|---|
| SA 335 Gr22 (P5A) | GTAW (Auto) | ER 309L + ER 347 |
| SA 336 F22 V (P5C) | GTAW (Auto) | ER 309L + ER 347 |
| SA 182 Gr11 Cl2 (P4) | GTAW (Auto) | ER 309L + ER 347 |
| SA 335 P11(P4) | GTAW (Auto) | ER 309LMo + ER 316LSi |
| SA 335 P11 (P4) | GTAW (Auto) | ER 309L + ER 308LSi |
III. Carbon steel + weld overlay nickel based
| Base material | Procedure | Welding material |
|---|---|---|
| SA 106 Gr B (P1) | GTAW (Auto) | ER NiFeCr1 (Alloy 825) |
| SA 106 Gr B (P1) | GTAW (Auto) | ER NiCr7 (Alloy 690) Nuclear |
| SA 106 Gr B (P1) | GTAW (Auto) | ER NiCu7 (Monel 400) |
| SA 106 Gr B (P1) | GTAW (Auto) | ER Ni-1 (Niquel 200) |
| SA 106 Gr B (P1) | GTAW (Auto) | ER NiCrMo3 (Alloy 625) |
| SA 106 Gr B (P1) | GTAW (Auto) | ER NiCr3 (Alloy 82) |
| SA 106 Gr B (P1) | GTAW (Auto) | ER NiCrMo10 (Alloy C22) |
| SA 106 Gr B (P1) | GTAW (Auto) | ER Ni-1 (Niquel 200) + ER NiCu7 (Monel 400) |
IV. Chromium molybdenum alloy steel + weld overlay nickel based
| Base material | Procedure | Welding material |
|---|---|---|
| SA 182 Gr 11 Cl2 (P4) | GTAW (Auto) | ER NiCrMo13 (Alloy 59) |
| SA 182 Gr 22 (P5A) | GTAW (Auto) | ER NiCrMo3 (Alloy 625) |
| SA 182 Gr 11 Cl2 (P4) | GTAW (Auto) | ER NiCrMo3 (Alloy 625) |
| SA 335 P11 (P4) | GTAW (Auto) | ER NiCr3 (Alloy 82) |
V. Other materials
| Base material | Procedure | Welding material |
|---|---|---|
| SA 106 Gr B (P1) | GTAW (Auto) | ER CuNi 70/30 (cuproníquel) |
| SA 335 P9 (P9) | GTAW (Auto) | ER CCoCrA (Stellite Gr. 6) |
| AISI 304 H | GTAW (Auto) | ER CCoCrA (Stellite Gr. 6) |
| Incoloy 800 H | GTAW (Auto) | ER CCoCrA (Stellite Gr. 6) |
| 80 HLES | GTAW (Auto) | ER NiCrMo3 |
| A 204 GrA (P3) | GTAW (Auto) | ER CCoCrA (Stellite Gr. 6) |
| 410S (P7) | GTAW (Auto) | ER CCoCrA (Stellite Gr. 6) |
| AISI 316 (P8) | GTAW (Auto) | Colmonoy 5 |
Butt weld procedures
| Base material | Procedure | Welding material |
|---|---|---|
| SA 516 Gr 70 (P1) | GTAW + SMAW | ER 70S-6 + E7018 |
| SA 516 Gr 70 (P1) | GTAW + SAW | ER 70S-6 + EM12K |
| SA 106 Gr B (P1) | GTAW ORBITAL | ER 70S-6 |
| SA 335 P11 (P4) | GTAW+SMAW+SAW | ER 8018 B2/E 8018/5.23:EB2 |
| API 5L GrX70 | GTAW auto+SAW | ER 100S-1+S3niMo1 |
| SA 335 P9 (P9) | GTAW+GTAW (auto) | ER 80S B8 |
| SA 240 TP 321(P8) | GTAW+SMAW+SAW | ER 347 + E 347 + ER 347 |
| SA 240 TP 304 (P8) | GTAW auto | N/A |
| SA 240 TP 304 (P8) | GTAW + SMAW | ER 304 + E 304 |
| SA 240 TP 316L(P8) | GTAW + SAW | ER 316L |
| AVESTA 904L(P8) | GTAW (auto) | ER 385 |
| DUPLEX 2205 | GTAW + FCAW | ER 2209 + ET2209 |
| MONEL 400 | GTAW + SMAW | ER NiCu7 + E NiCu7 |
| C-276 | SMAW + GMAW | E NiCrMo4 + ER NiCrMo4 |
| EN 06625 | GTAW | ER NiCrMo3 |
| ALLOY C22 | GTAW + SMAW | ER NiCrMo10 |
| EN 06625+AISI 321 | GTAW | ER NiCrMo3 |
| URANUS 52 N+ | GTAW + GTAW auto | ER NiCrMo10 |
| TITANIO Gr 1 | GTAW + GTAW auto | TITANIO Gr.1 |
| TITANIO Gr 7 | GTAW + GTAW auto | TITANIO Gr.7 |
